IP video intercom kit DS-KIS604

Sh780,000

  • Door Station/System Parameters
  • Operation SystemEmbedded Linux operation system
  • Operation ModeSingle-button
  • Flash

    32 M

  • RAM

    256 M

  • Door Station/Video Parameters
  • Camera

    2MP HD camera

  • Night VisionLow illumination IR supplement mode:3 m
  • Backlight CompensationSupport
  • Digital Noise ReductionSupport
  • WDRTrue WDR
  • Field Of ViewHorizontal: 129° Vertical: 75°
  • Video Compression StandardH.264
  • Stream

    Main stream: 1080p@30fps, 720p@25fps

    Sub stream: D1@25fps

  • Motion DetectionSupport
  • Flash-Avoid Frequency50 Hz, 60 Hz
  • Door Station/Audio Parameters
  • Audio InputBuilt-in omnidirectional microphone
  • Audio OutputBuilt-in loudspeaker
  • Audio QualityNoise suppression and echo cancellation
  • Audio Compression StandardG.711 U
  • Audio Compression Rate64 Kbps
  • Audio Intercom

    Two-way audio communication

  • Door Station/Network Parameters
  • Network Protocol

    TCP/IP, RSTP

  • Wired Network10/100 Mbps Ethernet
  • Door Station/Device Interfaces
  • RS-485

    1

  • Alarm Input4
  • Debugging Port1
  • Grounding1
  • TAMPER Switch1
  • Door Station/General
  • Power Consumption

    < 10 W

  • Working Temperature-40° C to 53° C(-40° F to 127.4° F)
  • Working Humidity10% to 95%
  • Dimension174 mm × 91 mm × 29 mm
  • InstallationSurface mounting/ Flush mounting
  • Protection Level

    IP65, IK08

  • Indicator3
  • Power Supply

    IEEE802.3af, standard PoE

    12 VDC

  • Indoor Station/System Parameters
  • Operation SystemEmbedded Linux operation system
  • Memory128 MB
  • Flash32 MB
  • Indoor Station/Display Parameters
  • Display Screen7-inch colorful TFT screen
  • Display Resolution1024 × 600
  • Operation MethodCapacitive touch screen
  • Indoor Station/Audio Parameters
  • Audio InputBuilt-in omnidirectional microphone
  • Audio OutputBuilt-in loudspeaker
  • Audio Quality

    Noise suppression and echo cancellation

  • Audio Compression Standard

    G.711 U

  • Audio Compression Rate

    64 Kbps

  • Indoor Station/Network Parameters
  • Wired Network

    10/100 Mbps self-adaptive

  • Wireless Network

    Wi-Fi 802.11 b/g/n

  • Protocol

    TCP/IP, SIP, RTSP

  • Network Interface1 RJ-45 10/100 Mbps self-adaptive
  • Indoor Station/Device Interfaces
  • RS-4851
  • Alarm Input8-ch alarm inputs
  • Relay Output2
  • TF CardMax to 32 G, SD 2.0 or lower version
  • Indoor Station/General
  • Power Consumption

    ≤ 6 W

  • Working Temperature

    -10 °C to 55 °C (14 °F to 131 °F)

  • Working Humidity10% to 90%
  • Dimension (L X W X H)

    200 mm × 140 mm × 15.1 mm (7.9″ ×

    5.5 × 0.6\”)”

Brand

HIKVISION
